"Why use NMOS for the upper switch in DC-DC converters?" This topic is a common one for us electronic engineers. So, today, let's briefly discuss why NMOS is used for the upper switch in DC-DC converters instead of PMOS!

First, let's review the concept of DC-DC converters.

DC-DC, short for direct current - direct current converter, is a power circuit that converts one DC voltage to another DC voltage. It can be divided into two types: boost and buck. The NMOS we are discussing today refers to N-channel Metal-Oxide-Semiconductor Field-Effect Transistors. In DC-DC converters, NMOS plays an important role. So, how does it work?

In fact, in DC-DC converters, the choice of the upper switch mainly depends on its switching speed and on-state resistance. As we know, in MOSFETs, NMOS and PMOS are two common structures. So, why isn't PMOS used for the upper switch in DC-DC converters instead of NMOS? Let's start with their characteristics.

The biggest difference between NMOS and PMOS lies in their channel types.

The channel of NMOS is made of n-type semiconductor, while the channel of PMOS is made of p-type semiconductor. Due to the higher electron concentration of n-type semiconductor compared to p-type semiconductor, the electron mobility of NMOS is higher than that of PMOS. In other words, under the same electric field, the electron velocity in NMOS is faster than that in PMOS. This advantage makes NMOS perform better in high-frequency applications.

Additionally, NMOS has another advantage: the distance between its source and drain is shorter than that of PMOS. This advantage results in a lower on-state resistance of NMOS compared to PMOS, thereby providing better switching performance. In DC-DC converters, the upper switch needs to switch frequently, so NMOS with low on-state resistance is more suitable for this application.

Interestingly, although NMOS has many advantages in DC-DC converters, PMOS is not without its merits. In fact, in some specific application scenarios, PMOS is more popular. For example, in high-voltage and high-current applications, PMOS is often more advantageous due to its higher breakdown voltage and lower on-state resistance than NMOS.

So, back to our question: "Why use NMOS for the upper switch in DC-DC converters?"

The answer is quite clear: NMOS has higher electron mobility and lower on-state resistance, making it superior in switching performance in DC-DC converters. However, we should not overlook the advantages of PMOS in certain specific scenarios. In practical applications, the choice of MOSFET type should be based on the actual requirements of the circuit.
